1: product usage

The product can adjust the output voltage continuously, smoothly and continuously under the condition of load. Used mainly of industries such as electrics machines, metallurgical, chemical, communications, military and other industries for load voltage regulation.

2: Product performance

a. Small no load current, low total loss, efficiency more than 96%;

b. The output voltage can be regulated steepless ,smoothly and continuously under load condition;

c. Suitable for various loads and has high over load capacity;

d. Output voltage waveform distortion small;

e. Easy to use and maintain.

3: product specifications

Product model

Cooling method

Rated capacity kVA

Phase number

frequency Hz

Rated input voltage  V

Output voltage range V

TDA-xxx

Oil

Since the cold

12.5～400

1

50

（60）

220

0～250或0～400

12.5～400

380

0～420或0～500

12.5～800

0～650

10～630

0～1000

TDA-xxx/6.3

400～2500

6000

0～6300

TDA-xxx/10.5

400～2500

0～10500

TDA-xxx/10

250～1600

10000

0～6300

TDA-xxx/10.5

315～2000

0～10500

TDA-xxx/13

315～2000

6000或10000

0～13000

TSA-xxx

20～1250

3

380

0～420或0～500

20～3150

0～650

16～2500

0～1000

TSA-xxx/6.3

630～12500

6000

0～6300

TSA-xxx/10.5

630～12500

0～10500

TSA-xxx/10

400～8000

10000

0～6300

TSA-xxx/10.5

500～10000

0～10500

TSA-xxx/13

500～10000

6000或10000

0～13000

TDFA-xxx

Dry

Air cooling

25～315

1

50

（60）

220

0～250或0～400

25～315

380

0～420或0～500

25～1000

0～650

16～630

0～1000

TSFA-xxx

31.5～1000

3

380

0～420或0～500

40～1600

0～650

31.5～1250

0～1000

notes：①The XXX data indicates the rated capacity in the product model；

②Voltage regulators designed according to the 50Hz can also be used in 60Hz power supplies；

③Capacity is in line with the R10 priority number：12.5、16、20、25、31.5、40、50、63、80、100、125、160、200、250、315、400、500、630、800、1000、1250、1600、2000、2500、3150、4000、5000、6300、8000、10000、12500kVA；

④Capacity and voltage specifications in this table are not available. The enterprise can also undertake design and manufacture.
